84909 / 85909 Air Angle Grinder – 4″ & 5″ Heavy-Duty Cut Off Tools

84909 & 85909 Heavy-Duty Air Angle Grinder |

SKU 84909/85909 Categories Pneumatic Impact Wrench/ Air Tools, Air Tools Tags Air Tools, Cutter, Die Grinder

84909 / 85909 Air Angle Grinder – 4″ & 5″ Heavy-Duty Cut Off Tools

84909 / 85909 Air Angle Grinder – 4″ & 5″ Cut Off Tools
Meuleuse d’angle pneumatique – modèles 4″ et 5″
Pneumatyczna szlifierka kątowa – modele 4″ i 5″
Pneumatischer Winkelschleifer – 4″ und 5″ Ausführung
Esmeriladora angular neumática – modelos de 4″ y 5″
طاحونة زاوية هوائية – موديلات ٤ و ٥ بوصة
เครื่องเจียรมุมลม – ขนาดจาน 4″ และ 5″
84909 / 85909 氣動角向砂輪機－4″ 與 5″ 重負載切割
84909 / 85909 气动角向砂轮机－4″ 和 5″ 重负载切割
Impact Wrench- Pneumatic Power Instruction

Air Angle Grinder (Models 84909 and 85909) is a premium industrial-grade pneumatic tool engineered for aggressive material removal, heavy automotive body fabrication, weld preparation, rust scaling, and high-performance metal cutting. Designed to survive continuous operational loads on busy workshop floors, these heavy-duty grinders are built around a robust pneumatic motor and an ultra-durable angle head housing. By selecting either the compact 4-inch model (84909) or the high-capacity 5-inch model (85909), fabrication facilities and industrial maintenance operations can optimize their cutting depth and tool clearance to match any production requirement.

ITEM NO.	DISC SIZE inch/mm	SPINDLE SIZE	MOTOR H.P.	EXHAUST	FREE SPEED R.P.M.	AVG.DLR CONSUMPTION CFM
83909	3"/ 76.2	3/8"	0.5	REAR	20000	4
84908-14	4"/ 102	3/8"	0.5	REAR	15000	7
84909	4"/ 102	3/8"	0.85	REAR	12000	6
85909	5"/ 127	3/8"	0.85	REAR	12000	6

ITEM NO.	AIR PRESSURE BAR (PSI)	AIR INLET INCH	AIR HOSE ID	OVERALL LENGTH inch/mm	KGS	pcs
83909	90 PSI 6.2 BAR	1/4	3/8	7.6"/ 190	0.8	20
84908-14	90 PSI 6.2 BAR	1/4	3/8	14"/ 350	1.1	10
84909	90 PSI 6.2 BAR	1/4	3/8	242mm	1.82	12
85909	90 PSI 6.2 BAR	1/4	3/8	242mm	1.9	12

Feature

Heavy-duty air angle grinder / cut off tool for metal cutting, rust removal and weld preparation
Disc sizes: 4″ (84909) and 5″ (85909) for different cutting depth and coverage
0.85 HP motor, 12,000 RPM free speed on both models for strong cutting and grinding performance
Rear exhaust directs air away from the cutting line and operator
Average air consumption: approx. 6 CFM for efficient use with workshop compressors
Operating pressure: 6.2 bar / 90 PSI, air inlet: 1/4″, air hose ID: 3/8″ – fits standard air systems
Overall length: 242 mm for both models, with net weight 1.82 kg (84909) and 1.9 kg (85909)
Spiral bevel angle head and side handle provide control, durability and reduced vibration in continuous use
