1823 VDE High-Leverage Insulated Combination Pliers | 1000V Certified
1823 VDE High-Leverage Insulated Combination Pliers: 1000V Certified
- 1823 VDE 高倍力絕緣鋼絲鉗 (1000V 安全認證)
- 1823 VDE 高倍力绝缘钢丝钳 (1000V 安全认证)
- 1823 Alicate Universal Aislado de Alta Palanca VDE (Seguridad 1000V)
- 1823 VDE Kraft-Kombizange Isoliert (1000V Zertifiziert)
- 1823 Pince Universelle Isolée VDE à Forte Démultiplication (Certifiée 1000V)
- 1823 زرادية مشتركة معزولة عالية الرافعة VDE (أمان معتمد 1000V)
- 1823 VDE Geïsoleerde Hoogwaardige Combinatietang (1000V Gecertificeerd)
- ۱۸۲۳ انبردست عایق فشار قوی VDE (گواهینامه امنیت 1000V)
- 1823 Izolowane Szczypce Uniwersalne Kombinerki VDE o Zwiększonej Dźwigni (Certyfikat 1000V)
- 1823 VDE Szigetelt Erő-Kombinált Fogó (1000V Tanúsított)
- 1823 Изолированные комбинированные пассатижи повышенной мощности VDE (Сертификат 1000В)
- 1823 Alicate Universal Isolado de Alta Alavancagem VDE (Certificação 1000V)
- 1823 Pinza Universale Isolata VDE ad Alta Leva (Certificata 1000V)
- 1823 VDE 絕緣高レバー比コンビネーションプライヤー (1000V 安全認証)
- 1823 VDE 절연 고레버리지 양용 펜치 (1000V 안전인증)
- 1823 คีมรวมหุ้มฉนวนกันไฟฟ้าแรงบิดสูง VDE (มาตรฐานความปลอดภัย 1000V)
- 1823 Kìm răng kết hợp cách điện lực kéo cao VDE (Chứng nhận 1000V)
- Insulated Tools in Safety concern
Insulated combination pliers for electrical and maintenance work. Serrated gripping jaws hold flats and round stock; induction-hardened cutters handle Cu/Al conductors and soft wire. Non-slip insulated grips support control with gloves.
| 1828 | L mm/inch | L3 mm | W3 mm | W4 mm | T1 mm |  g |  Cutting mm |  pcs |
|---|---|---|---|---|---|---|---|---|
| 7 | 180/ 7" | 39 | 26.4 | 4.6 | 10.6 | 280 | 1.6  | 6 |
| 8 | 200/ 8" | 41.5 | 28.6 | 6.6 | 11.2 | 360 | 1.6 | 6 |
Feature
Material Engineering & Structural Truth
High-Leverage Eccentric Pivot Physics
The internal mechanical advantage of the 1823 design is improved by placing the central pivot rivet closer to the jaw head assembly. This reduces the pivot distance between the pivot center and the cutting tracks. As a result, the output force applied to the material becomes stronger compared with the user’s input hand force.
Force Multiplier Formula
Foutput = Finput × (Lhandle ÷ Lpivot)
The tool increases your hand force by using a long handle and a short pivot distance.
In simple terms: the longer the handle is, and the shorter the pivot distance is, the more force the jaws can deliver to the material.
Because the pivot distance is much shorter than on standard multi-purpose pliers, the tool works as an exceptional force multiplier. This supports easier cutting through thick conductors and stronger gripping power at the flat front tip.
Tri-Zone Functional Jaw Geometry
- Flat Cross-Serrated Front Tip: Designed to tightly hold flat sheet metal stock, wire strands, and brackets without twisting out of alignment under heavy rotational torque.
- Curved Tooth Burner Hole (Pipe Grip): Features aggressive, deeply cut hardened teeth arranged in a curved radius. This profile locks onto rounded objects like round stock, pipe walls, threaded conduit, and rusty hex nuts with intense traction.
- Induction-Hardened Cutting Edge: Positioned closest to the pivot point for extreme cutting efficiency, these blades are hardened to clean-shear copper, multi-core cables, and medium-hard iron wire.
IEC 60900 Dual-Material Insulation Shield
The heavy-walled safety grips are injection-molded directly over the knurled metal anchors of the drop-forged alloy frame. The molded high-profile finger guards form an absolute physical block, making it impossible for the technician’s fingers to slide forward onto the exposed steel parts while working under live current.
- Technical FAQ: Insulated Combination Wrench Optimization
Q: When should an industrial technician deploy the 1823 Combination Pliers instead of a dedicated diagonal cutter or long nose plier?
A: When performing multi-functional, heavy-duty electrical tasks that demand both maximum crushing grip and high-tensile shearing. Long-nose models are designed for precision wiring in tight, deep areas, and diagonal cutters are dedicated solely to clean trimming. The Hans 1823 combination plier balances both worlds, allowing you to firmly grab heavy conduit, pull thick industrial wire through conduit runs, and cleanly cut electrical lines without constantly switching tools.
Q: How does the flat cross-hatched tip pattern compare to straight inline serrations?
A: Omnidirectional grip stability. Straight inline jaw serrations hold material firmly in only one direction, meaning they can easily slide loose if twisted sideways. The Hans 1823 features a precision cross-hatched diamond serration pattern, locking onto wire leads and hardware uniformly across all axes (X and Y). This allows you to apply intense twisting and forming force without slipping or damaging the workpiece.
