1860-06 Insulated High-Leverage Diagonal Cutter 6″
1860-06 Insulated High-Leverage Diagonal Cutting Nipper – 6″
- 1860-06 Insulated High-Leverage Diagonal Cutting Nipper (6″)
- 1860-06 絕緣高倍力斜口鉗（6″）
- 1860-06 绝缘高倍力斜口钳（6″）
- 1860-06 Alicate de Corte Diagonal Aislado de Alta Palanca (6″)
- 1860-06 Isolierter Kraft-Seitenschneider 6″
- 1860-06 Pince Coupante Diagonale Isolée Haute Leverage 6″
- 1860-06 قاطع جانبي معزول عالي الرافعة 6″
1860-06 is a 6-inch insulated side cutter built for panel and harness work. The high-leverage pivot reduces hand force, while induction-hardened cutting edges deliver clean cuts on copper/aluminum conductors and cable ties. Red/Yellow insulation is tested to industry live-work standards (IEC 60900*).
1860-06 Insulated High-Leverage Diagonal Cutter 6″
| 1860 | L mm/inch | L3 mm | W3 mm | T1 mm |  g |  Cutting mm |  pcs |
|---|---|---|---|---|---|---|---|
| 6 | 160/ 6" | 21.1 | 20.6 | 11.7 | 220 | 1.6  | 6 |
Feature
- High-leverage joint – more cut power with less effort
- Induction-hardened edges for long life and crisp cuts
- Slim head for tight panels; precision ground cutting face
- IEC 60900 insulated handles* (1000 V AC / 1500 V DC – confirm print)
- Anti-slip safety flanges; corrosion-resistant steel body
- Spring-free design for durability in shop environments
Where it wins (field scenarios)
- Switchgear & control panels: quick, clean conductor trimming
- Harness loom work: flush trimming of cable ties without snagging
- EV/HEV service bays: insulated grip for energized environments*
Pro tips
- Angle the jaws slightly off-flat to avoid nicking adjacent insulation.
- For hard wire (piano/steel), use rated capacity only—or switch to a hard-wire cutter.
